Equipment List
Conventional Vertical Milling
Button
CNC 5 Axis Rotary Axis Milling Center
CNC 5 AXIS ROTARY AXIS MILLING CENTER
CNC Lathe
Button
Conventional Lathes
Button
CNC Water Jet Cutting Unit
Button
Flame & Plasma Cutting Unit
Button
Angler Surface Grinders
Button
Surface Grinders
Button
ROBOTIC PTA WELDING UNIT WITH ROTARY UNIT
Button
JET KOTE WELDING UNIT (COLD PROCESS)
Button
250 TON HYDRAULIC PRESS
Button
INDUCTION WELDING UNIT
Button
HYD MECH S-23A
Button
MORI SEIKI SH-500
- X-24.89″, Y-23.62″ & Z-25.59″
- Dual Pallet 19.68″ x 19.68″
- 120 ATC
- 40 Taper
- High Pressure coolant through spindle
- Max 12,000 RPM
| Specifications | Values | |
|---|---|---|
| Capacity | Pallet W | 500mm/19.7 inch |
| Pallet L | 500mm/19.7 inch | |
| Spindle | Spindle Taper | 40 |
| Maximum Speed | 12000 RPM | |
| Magazine | Number of Tools | 40 |
| Feed Axes | Travel (X Axis) | 630mm/24.8 inch |
| Travel (Y Axis) | 600mm/23.6 inch | |
| Travel (Z Axis) | 650mm/25.6 inch |
MAZAK- VC NEXUX 510C-II
- Max machining length
- 29.5″ MaxSwing
- 16.53 Max Turning Dia
- 3″ max bar capacity
- 3.46″ bore with Live tooling
| Specifications | Values | |
|---|---|---|
| Capacity | Table Right/Left | 1300mm/51.180 inch |
| Table Longitudinal | 550mm/21.650 inch | |
| Spindle | Spindle Taper | 40 |
| Maximum Speed | 12000 RPM | |
| Motor Output (30 minute rating) | 11 kw/15.0hp | |
| Magazine | Number of Tools | 40 |
| Feed Axes | Travel (X Axis) | 1050mm/41.34 inch |
| Travel (Y Axis) | 530mm/20.87 inch | |
| Travel (Z Axis) | 510mm/20.8 inch |
MAZAK QT NEXUS-300M
- Max machining length
- 29.5″ MaxSwing
- 16.53 Max Turning Dia
- 3″ max bar capacity
- 3.46″ bore with Live tooling
| Specifications | Bed Length /26 in | Bed Length/50 in | |
|---|---|---|---|
| Capacity | Maximum Swing | 720 mm/28.35 in | 720 mm/28.35 in |
| Maximum Machining Diameter | 420 mm/16.500 in | 420 mm/16.500 in | |
| Maximum Bar Work Capacity | 77 mm/3.0 in | 77 mm/3.0 in | |
| Maximum Machining Length | 654 mm/25.725 in | 1274 mm/50.225 in | |
| Main Spindle | Chuck Size | 10 in | 10 in |
| Maximum Speed | 4000 rpm | 4000 rpm | |
| Motor Output (30 minute rating) | 26 kw/35.0hp | 26 kw/35.0hp | |
| Turret (Upper) | Number of Tools | 12 | 12 |
| Maximum Speed | 4000 rpm | 4000 rpm | |
| Motor Output (10 minute rating) | 8 kw/10.0hp | 8 kw/10.0hp | |
| Feed Axes | Travel (X Axis) | 265mm/10.38 inch | 265mm/10.38 inch |
| Travel (Z Axis) | 730mm/28.63 inch | 1350mm/53.13 inch |
HURCO VM10I
| Specifications | Values | |
|---|---|---|
| Capacity | Max weight on table | 3300 lbs (1500kg) |
| Table Size | 762 x 406 mm / 30 x 16 in | |
| Spindle | Spindle Power (peak-1 min) | 15hp (11.0kW) |
| Maximum Speed | 12000 RPM | |
| Spindle Torque (peak-1 min) | 54.3 ft lbs 1450 rpm (73.6Nm @ 1450rpm) | |
| Magazine | Number of Tools | 24 |
| Feed Axes | Travel (X Axis) | 660mm/26 in |
| Travel (Y Axis) | 406mm/16 in | |
| Travel (Z Axis) | 508mm/20 in |
HURCO VM20I
| Specifications | Values | |
|---|---|---|
| Capacity | Max weight on table | 3970 lbs (1800kg) |
| Table Size | 1168 x 508 mm / 46 x 20 in | |
| Spindle | Spindle Power (peak-1 min) | 20hp (15.0kW) |
| Maximum Speed | 12000 RPM |
